Bluetooth

Here is some sample code for pairing your iOS app with a Bluetooth LE peripheral. I'd like to think of it as a good starting point for your particular use-case, where you'd likely make a lot of changes. It handles the usual requirements like service discovery, reconnecting automatically when you come in and out of range, and reconnecting on app startup.

Before you simply copy and paste and use it, please read my earlier Bluetooth article for background and other necessary information.

How to use this

  • Customise the service id, characteristic id, and the desired manufacturer data.
  • In your AppDelegate, prod the singleton to life with _ = MyBluetoothManager.shared
  • Call MyBluetoothManager.shared.scan() when you'd like to scan for the peripheral.
  • Implement some sort of notification system for whenever the state changes, eg in a didChange handler, and listen to this from other parts of your app to eg progress the UI to the 'paired' screen.
  • Call MyBluetoothManager.shared.disconnect(forget: true) when the user wants to unpair.
  • Call MyBluetoothManager.shared.write(data: foo) when you'd like to send data to the peripheral.
  • Customise didUpdateValueFor characteristic to handle data coming from the peripheral.
  • And of course, being Bluetooth, cross your fingers and hope for the best!

MIT license applies.

import CoreBluetooth

private let restoreIdKey = "MyBluetoothManager"
private let peripheralIdDefaultsKey = "MyBluetoothManagerPeripheralId"
private let myDesiredServiceId = CBUUID(string:
    "12345678-0000-0000-0000-000000000000")
private let myDesiredCharacteristicId = CBUUID(string:
    "12345678-0000-0000-0000-000000000000")
private let desiredManufacturerData = Data(base64Encoded: "foobar==")!
private let outOfRangeHeuristics: Set<CBError.Code> = [.unknown,
    .connectionTimeout, .peripheralDisconnected, .connectionFailed]

/// This manages a bluetooth peripheral. This is intended as a starting point
/// for you to customise from.
/// Read http://www.splinter.com.au/2019/05/18/ios-swift-bluetooth-le for a
/// background in how to set this all up.
class MyBluetoothManager {
    static let shared = MyBluetoothManager()

    let central = CBCentralManager(delegate: MyCentralManagerDelegate.shared,
        queue: nil, options: [
        CBCentralManagerOptionRestoreIdentifierKey: restoreIdKey,
        ])

    /// The 'state machine' for remembering where we're up to.
    var state = State.poweredOff
    enum State {
        case poweredOff
        case restoringConnectingPeripheral(CBPeripheral)
        case restoringConnectedPeripheral(CBPeripheral)
        case disconnected
        case scanning(Countdown)
        case connecting(CBPeripheral, Countdown)
        case discoveringServices(CBPeripheral, Countdown)
        case discoveringCharacteristics(CBPeripheral, Countdown)
        case connected(CBPeripheral)
        case outOfRange(CBPeripheral)

        var peripheral: CBPeripheral? {
            switch self {
            case .poweredOff: return nil
            case .restoringConnectingPeripheral(let p): return p
            case .restoringConnectedPeripheral(let p): return p
            case .disconnected: return nil
            case .scanning: return nil
            case .connecting(let p, _): return p
            case .discoveringServices(let p, _): return p
            case .discoveringCharacteristics(let p, _): return p
            case .connected(let p): return p
            case .outOfRange(let p): return p
            }
        }
    }

    // Begin scanning here!
    func scan() {
        guard central.state == .poweredOn else {
            print("Cannot scan, BT is not powered on")
            return
        }

        // Scan!
        central.scanForPeripherals(withServices: [myDesiredServiceId], options: nil)
        state = .scanning(Countdown(seconds: 10, closure: {
            self.central.stopScan()
            self.state = .disconnected
            print("Scan timed out")
        }))
    }

    /// Call this with forget: true to do a proper unpairing such that it won't
    /// try reconnect next startup.
    func disconnect(forget: Bool = false) {
        if let peripheral = state.peripheral {
            central.cancelPeripheralConnection(peripheral)
        }
        if forget {
            UserDefaults.standard.removeObject(forKey: peripheralIdDefaultsKey)
            UserDefaults.standard.synchronize()
        }
        state = .disconnected
    }

    func connect(peripheral: CBPeripheral) {
        // Connect!
        // Note: We're retaining the peripheral in the state enum because Apple
        // says: "Pending attempts are cancelled automatically upon
        // deallocation of peripheral"
        central.connect(peripheral, options: nil)
        state = .connecting(peripheral, Countdown(seconds: 10, closure: {
            self.central.cancelPeripheralConnection(peripheral)
            self.state = .disconnected
            print("Connect timed out")
        }))
    }

    func discoverServices(peripheral: CBPeripheral) {
        peripheral.delegate = MyPeripheralDelegate.shared
        peripheral.discoverServices([myDesiredServiceId])
        state = .discoveringServices(peripheral, Countdown(seconds: 10, closure: {
            self.disconnect()
            print("Could not discover services")
        }))
    }

    func discoverCharacteristics(peripheral: CBPeripheral) {
        guard let myDesiredService = peripheral.myDesiredService else {
            self.disconnect()
            return
        }
        peripheral.delegate = MyPeripheralDelegate.shared
        peripheral.discoverCharacteristics([myDesiredCharacteristicId],
            for: myDesiredService)
        state = .discoveringCharacteristics(peripheral, Countdown(seconds: 10,
            closure: {
            self.disconnect()
            print("Could not discover characteristics")
        }))
    }

    func setConnected(peripheral: CBPeripheral) {
        guard let myDesiredCharacteristic = peripheral.myDesiredCharacteristic
            else {
            print("Missing characteristic")
            disconnect()
            return
        }

        // Remember the ID for startup reconnecting.
        UserDefaults.standard.set(peripheral.identifier.uuidString,
            forKey: peripheralIdDefaultsKey)
        UserDefaults.standard.synchronize()

        // Ask for notifications when the peripheral sends us data.
        // TODO another state waiting for this?
        peripheral.delegate = MyPeripheralDelegate.shared
        peripheral.setNotifyValue(true, for: myDesiredCharacteristic)

        state = .connected(peripheral)
    }

    /// Write data to the peripheral.
    func write(data: Data) throws {
        guard case .connected(let peripheral) = state else {
            throw Errors.notConnected
        }
        guard let characteristic = peripheral.myDesiredCharacteristic else {
            throw Errors.missingCharacteristic
        }
        peripheral.writeValue(data, for: characteristic, type: .withoutResponse)
        // .withResponse is more expensive but gives you confirmation.
        // It's an exercise for the reader to ask for a response and handle
        // timeouts waiting for said response.
        // I found it simpler to deal with that at a higher level in a
        // messaging framework.
    }

    enum Errors: Error {
        case notConnected
        case missingCharacteristic
    }

}

extension CBPeripheral {
    /// Helper to find the service we're interested in.
    var myDesiredService: CBService? {
        guard let services = services else { return nil }
        return services.first { $0.uuid == myDesiredServiceId }
    }

    /// Helper to find the characteristic we're interested in.
    var myDesiredCharacteristic: CBCharacteristic? {
        guard let characteristics = myDesiredService?.characteristics else {
            return nil
        }
        return characteristics.first { $0.uuid == myDesiredCharacteristicId }
    }
}

class MyPeripheralDelegate: NSObject, CBPeripheralDelegate {
    static let shared = MyPeripheralDelegate()

    func peripheral(_ peripheral: CBPeripheral, didDiscoverServices error: Error?) {
        // Ignore services discovered late.
        guard case .discoveringServices = MyBluetoothManager.shared.state else {
            return
        }

        if let error = error {
            print("Failed to discover services: \(error)")
            MyBluetoothManager.shared.disconnect()
            return
        }
        guard peripheral.myDesiredService != nil else {
            print("Desired service missing")
            MyBluetoothManager.shared.disconnect()
            return
        }

        // Progress to the next step.
        MyBluetoothManager.shared.discoverCharacteristics(peripheral: peripheral)
    }

    func peripheral(_ peripheral: CBPeripheral,
            didDiscoverCharacteristicsFor service: CBService, error: Error?) {
        // Ignore characteristics arriving late.
        guard case .discoveringCharacteristics =
            MyBluetoothManager.shared.state else { return }

        if let error = error {
            print("Failed to discover characteristics: \(error)")
            MyBluetoothManager.shared.disconnect()
            return
        }
        guard peripheral.myDesiredCharacteristic != nil else {
            print("Desired characteristic missing")
            MyBluetoothManager.shared.disconnect()
            return
        }

        // Ready to go!
        MyBluetoothManager.shared.setConnected(peripheral: peripheral)
    }

    func peripheral(_ peripheral: CBPeripheral,
            didUpdateValueFor characteristic: CBCharacteristic, error: Error?) {
        if let error = error {
            print(error)
            return
        }

        // This is where the peripheral sends you data!
        // Exercise for the reader: handle the characteristic.value, eg buffer
        // and scan for JSON between STX and ETX markers.
    }

    /// Called when .withResponse is used.
    func peripheral(_ peripheral: CBPeripheral,
            didWriteValueFor characteristic: CBCharacteristic, error: Error?) {
        if let error = error {
            print("Error writing to characteristic: \(error)")
            return
        }
    }

    func peripheral(_ peripheral: CBPeripheral,
            didUpdateNotificationStateFor characteristic: CBCharacteristic,
            error: Error?) {
        // TODO cancel a setNotifyValue timeout if no error.
    }
}

class MyCentralManagerDelegate: NSObject, CBCentralManagerDelegate {
    static let shared = MyCentralManagerDelegate()

    func centralManagerDidUpdateState(_ central: CBCentralManager) {
        if central.state == .poweredOn {
            // Are we transitioning from BT off to BT ready?
            if case .poweredOff = MyBluetoothManager.shared.state {
                // Firstly, try to reconnect:
                if let peripheralIdStr = UserDefaults.standard
                        .object(forKey: peripheralIdDefaultsKey) as? String,
                    let peripheralId = UUID(uuidString: peripheralIdStr),
                    let previouslyConnected = central
                        .retrievePeripherals(withIdentifiers: [peripheralId])
                        .first {
                    MyBluetoothManager.shared.connect(
                        peripheral: previouslyConnected)

                    // Next, try for ones that are connected to the system:
                } else if let systemConnected = central
                        .retrieveConnectedPeripherals(withServices:
                        [myDesiredServiceId]).first {
                    MyBluetoothManager.shared.connect(peripheral: systemConnected)

                } else {
                    // Not an error, simply the case that they've never paired
                    // before, or they did a manual unpair:
                    MyBluetoothManager.shared.state = .disconnected
                }
            }

            // Did CoreBluetooth wake us up with a peripheral that was connecting?
            if case .restoringConnectingPeripheral(let peripheral) =
                    MyBluetoothManager.shared.state {
                MyBluetoothManager.shared.connect(peripheral: peripheral)
            }

            // CoreBluetooth woke us with a 'connected' peripheral, but we had
            // to wait until 'poweredOn' state:
            if case .restoringConnectedPeripheral(let peripheral) =
                    MyBluetoothManager.shared.state {
                if peripheral.myDesiredCharacteristic == nil {
                    MyBluetoothManager.shared.discoverServices(
                        peripheral: peripheral)
                } else {
                    MyBluetoothManager.shared.setConnected(peripheral: peripheral)
                }
            }
        } else { // Turned off.
            MyBluetoothManager.shared.state = .poweredOff
        }
    }

    // Apple says: This is the first method invoked when your app is relaunched
    // into the background to complete some Bluetooth-related task.
    func centralManager(_ central: CBCentralManager,
            willRestoreState dict: [String : Any]) {
        let peripherals: [CBPeripheral] = dict[
            CBCentralManagerRestoredStatePeripheralsKey] as? [CBPeripheral] ?? []
        if peripherals.count > 1 {
            print("Warning: willRestoreState called with >1 connection")
        }
        // We have a peripheral supplied, but we can't touch it until
        // `central.state == .poweredOn`, so we store it in the state
        // machine enum for later use.
        if let peripheral = peripherals.first {
            switch peripheral.state {
            case .connecting: // I've only seen this happen when
                // re-launching attached to Xcode.
                MyBluetoothManager.shared.state =
                    .restoringConnectingPeripheral(peripheral)

            case .connected: // Store for connection / requesting
                // notifications when BT starts.
                MyBluetoothManager.shared.state =
                    .restoringConnectedPeripheral(peripheral)
            default: break
            }
        }
    }

    func centralManager(_ central: CBCentralManager,
            didDiscover peripheral: CBPeripheral,
            advertisementData: [String : Any], rssi RSSI: NSNumber) {
        guard case .scanning = MyBluetoothManager.shared.state else { return }

        // You might want to skip this manufacturer data check.
        guard let mfgData =
                advertisementData[CBAdvertisementDataManufacturerDataKey] as? Data,
            mfgData == desiredManufacturerData else {
            print("Missing/wrong manufacturer data")
            return
        }

        central.stopScan()
        MyBluetoothManager.shared.connect(peripheral: peripheral)
    }

    func centralManager(_ central: CBCentralManager,
            didConnect peripheral: CBPeripheral) {
        if peripheral.myDesiredCharacteristic == nil {
            MyBluetoothManager.shared.discoverServices(peripheral: peripheral)
        } else {
            MyBluetoothManager.shared.setConnected(peripheral: peripheral)
        }
    }

    func centralManager(_ central: CBCentralManager,
            didFailToConnect peripheral: CBPeripheral, error: Error?) {
        MyBluetoothManager.shared.state = .disconnected
    }

    func centralManager(_ central: CBCentralManager,
            didDisconnectPeripheral peripheral: CBPeripheral, error: Error?) {
        // Did our currently-connected peripheral just disconnect?
        if MyBluetoothManager.shared.state.peripheral?.identifier ==
                peripheral.identifier {
            // IME the error codes encountered are:
            // 0 = rebooting the peripheral.
            // 6 = out of range.
            if let error = error,
                (error as NSError).domain == CBErrorDomain,
                let code = CBError.Code(rawValue: (error as NSError).code),
                outOfRangeHeuristics.contains(code) {
                // Try reconnect without setting a timeout in the state machine.
                // With CB, it's like saying 'please reconnect me at any point
                // in the future if this peripheral comes back into range'.
                MyBluetoothManager.shared.central.connect(peripheral, options: nil)
                MyBluetoothManager.shared.state = .outOfRange(peripheral)
            } else {
                // Likely a deliberate unpairing.
                MyBluetoothManager.shared.state = .disconnected
            }
        }
    }
}

/// Timer wrapper that automatically invalidates when released.
/// Read more: http://www.splinter.com.au/2019/03/28/timers-without-circular-references-with-pendulum
class Countdown {
    let timer: Timer

    init(seconds: TimeInterval, closure: @escaping () -> ()) {
        timer = Timer.scheduledTimer(withTimeInterval: seconds,
                repeats: false, block: { _ in
            closure()
        })
    }

    deinit {
        timer.invalidate()
    }
}

Thanks for reading, and have a great week!

Photo by Katherine Chase on Unsplash

Thanks for reading! And if you want to get in touch, I'd love to hear from you: chris.hulbert at gmail.

Chris Hulbert

(Comp Sci, Hons - UTS)

iOS Developer (Freelancer / Contractor) in Australia.

I have worked at places such as Google, Cochlear, Assembly Payments, News Corp, Fox Sports, NineMSN, FetchTV, Woolworths, and Westpac, among others. If you're looking for help developing an iOS app, drop me a line!

Get in touch:
[email protected]
github.com/chrishulbert
linkedin
my resume



 Subscribe via RSS
