The Kalman Filter for Programmers

Hi all, here’s how to implement the Kalman filter from scratch, in C-ish pseudocode. The intended audience is developers, as opposed to mathematicians, so there will be no complicated formulae - just additions, subtractions, and multiplications. I won’t try to explain the theory behind the Kalman filter and its intended uses, that is explained far better elsewhere (Wikipedia is a great place to start). To oversimplify, it’s a little like a moving average.

This article explains how to implement a position-only Kalman filter, as a stepping stone to implementing a position-and-velocity filter in my next article.

Firstly, you’ll need the ‘external noise variance’. This is usually referred to as Q in Kalman literature:

const double Q_EXTERNAL_NOISE_VARIANCE = 0.1

Next, you’ll need the ‘measurement noise variance’, aka R in Kalman articles:

const double R_MEASUREMENT_NOISE_VARIANCE = 0.1

How do you select good Q and R values? I’m not an expert, but here’s my two tips:

  • If you’re filtering a sensor that has a normal / gaussian distribution vs the actual value, use the variance of its inaccuracy as R (variance = average[residual^2], residual = measurement - actual value), and experiment with Q until it works the way you’d like.
  • If you’re filtering non-gaussian data (eg stock prices), simply experiment with Q and R until you’re happy with it. I’d write a program to generate a million random Q+R pairs, then choose the pair that predicts the ‘next’ data points best. That is an (whopping) exercise for the reader, sorry!

Next, we need our ‘state transition matrix’, aka F in Kalman articles. Since this is the one-dimensional filter, this is a simple double that, when multiplied by a data point, gives us our expected next data point. Eg it’ll simply be 1.

const double F_STATE_TRANSITION = 1

Next, we need the ‘state error’, aka P in Kalman articles. I find it usually works fine to start filtering with this as 1:

double pStateError = 1

Next, we need our ‘current state’, aka X in Kalman articles. Start filtering with this set to the first measurement:

double xCurrentState = data[0]

Now a prerequisite: transposing a ‘matrix’. In our simple one-dimensional case, this is a no-op, but I’m leaving it here as a stepping stone to the next article:

double transpose(double a) { return a }

Another prerequisite: inverting a ‘matrix’. In our simple case, this is just 1 / a.

double invert(double a) { return 1 / a }

Now for the interesting bit. For each new data point/measurement, we need to first predict what it’ll be, then blend that prediction with the measurement to produce an estimate. This estimate is the filter’s output. A ‘Kalman gain’ (known as K in Kalman articles) is calculated that is used to weight the prediction vs measurement when blending them to form the estimate.

// Make predictions.
double xPredicted = F_STATE_TRANSITION * xCurrentState
double pPredicted = F_STATE_TRANSITION * pStateError * transpose(F_STATE_TRANSITION) + Q_EXTERNAL_NOISE_VARIANCE

// Update it with the measurement.
double zMeasurement = data[current_index]
double kKalmanGain = pPredicted * invert(pPredicted + R_MEASUREMENT_NOISE_VARIANCE)
double xEstimate = xPredicted + kKalmanGain * (zMeasurement - xPredicted)
double pEstimate = pPredicted - kKalmanGain * pPredicted

// Setup for the next iteration.
pStateError = pEstimate
xCurrentState = xEstimate // This is the output!

You may find my next article about position-and-velocity Kalman filters helpful!

Thanks for reading, I hope this helps, God bless, and have a nice week :)
