Hi all, here’s how to implement a position-and-velocity Kalman filter from scratch, in C++ish pseudocode, from the perspective of a developer who isn’t a professional mathematician and doesn’t understand the kind of symbology used in many Kalman articles. I wrote another article about a simpler Kalman filter as a primer on the subject, if you read it first it will hopefully help make this article easier to understand.

Firstly we need to implement some matrix maths stuff as a prerequisite. It might help to skim-read Wikipedia on the topic first.

```
// A 2-row column vector.
struct Vector {
double a // aka Position or Price
double b // aka Velocity
}
// A 2x2 matrix.
struct Matrix {
double tl // Top Left, eg row 1 column 1
double tr // Top right, r1c2
double bl // Bottom left, r2c1
double br // Bottom right, r2c2
}
// vectorA + vectorB.
+(Vector lhs, Vector rhs) -> Vector {
return Vector {
a: lhs.a + rhs.a,
b: lhs.b + rhs.b
}
}
// vectorA - vectorB.
-(Vector lhs, Vector rhs) -> Vector {
return Vector(
a: lhs.a - rhs.a,
b: lhs.b - rhs.b
)
}
// matrixA + matrixB.
+(Matrix lhs, Matrix rhs) -> Matrix {
return Matrix(
tl: lhs.tl + rhs.tl, tr: lhs.tr + rhs.tr,
bl: lhs.bl + rhs.bl, br: lhs.br + rhs.br
)
}
// matrixA - matrixB.
-(Matrix l, Matrix r) -> Matrix {
return Matrix(
tl: l.tl - r.tl, tr: l.tr - r.tr,
bl: l.bl - r.bl, br: l.br - r.br
)
}
// matrixA * matrixB.
*(Matrix l, Matrix r) -> Matrix {
return Matrix(
tl: l.tl * r.tl + l.tr * r.bl,
tr: l.tl * r.tr + l.tr * r.br,
bl: l.bl * r.tl + l.br * r.bl,
br: l.bl * r.tr + l.br * r.br
)
}
// vectorOutput = matrixA * vectorB.
*(Matrix m, Vector v) -> Vector {
return Vector(
a: m.tl * v.a + m.tr * v.b,
b: m.bl * v.a + m.br * v.b
)
}
// Invert a matrix (the matrix version of 1 / m).
invert(Matrix m) -> Matrix {
return Matrix(
tl: m.br, tr: -m.tr,
bl: -m.bl, br: m.tl
)
}
// Transpose a matrix (mirror it diagonally).
transpose(Matrix m) -> Matrix {
return Matrix(
tl: m.tl, tr: m.bl,
bl: m.tr, br: m.br
)
}
```

Next, you’ll need the ‘external noise covariance matrix’. This is usually referred to as Q in Kalman literature:

```
const double Q_POSITION_VARIANCE = 0.1
const double Q_VELOCITY_VARIANCE = 0.1
const double Q_POSITION_VELOCITY_COVARIANCE = 0.1
const Matrix Q_EXTERNAL_NOISE = {
tl: Q_POSITION_VARIANCE, tr: Q_POSITION_VELOCITY_COVARIANCE,
bl: Q_POSITION_VELOCITY_COVARIANCE, br: Q_VELOCITY_VARIANCE,
}
```

Next, you’ll need the ‘measurement noise covariance matrix’, aka R in Kalman articles:

```
const double R_POSITION_VARIANCE = 0.1
const double R_VELOCITY_VARIANCE = 0.1
const double R_POSITION_VELOCITY_COVARIANCE = 0.1
const Matrix R_MEASUREMENT_NOISE = {
tl: R_POSITION_VARIANCE, tr: R_POSITION_VELOCITY_COVARIANCE,
bl: R_POSITION_VELOCITY_COVARIANCE, br: R_VELOCITY_VARIANCE,
}
```

How do you select good Q and R values? I’m not an expert, but here’s my two tips:

- If you’re filtering position and velocity sensors that have a normal / gaussian error, and they really are separate sensors as opposed to faking velocity by nowPosition-lastPosition, use the variance and covariance of the two sensors for R, and perhaps experiment with Q until it works the way you’d like. Variance = average[residual^2], covariance = average[positionResidual * velocityResidual], residual = measuredValue - realValue. If you don’t have real values, you could try substituting some kind of moving average.
- If you’re filtering non-gaussian data (eg stock prices), or your velocity is faked, simply experiment with Q and R until you’re happy with the filter performance. I’d write a program to generate a million random Q+R pairs, then choose the pair that predicts ‘next’ data points best. That is a (whopping) exercise for the reader, sorry!

Next, we need our ‘state transition matrix’, aka F in Kalman articles. This is a constant matrix that, when multiplied by the current state vector (position + velocity), gives us our expected next state vector (old position + velocity, same velocity). Eg it looks like:

```
const Matrix F_STATE_TRANSITION = {
tl: 1, tr: 1,
bl: 0, br: 1,
}
```

Maybe the above needs more explaining. Say our old state is position 100m, velocity 10m/s. Multiplying this by F works out like so:

```
Normal matrix * vector formula:
a: mat.tl * vec.a + mat.tr * vec.b,
b: mat.bl * vec.a + mat.br * vec.b
```

AKA:

```
new position: f.tl * position + f.tr * velocity
new velocity: f.bl * position + f.br * velocity
```

AKA:

```
new position: 1 * position + 1 * velocity
new velocity: 0 * position + 1 * velocity
```

AKA:

```
new position: position + velocity
new velocity: velocity
```

AKA:

```
new position: 110m
new velocity: 10m/s
```

In other words, for a timestep of 1 second, F simply adds the velocity-per-second to the current position, and assumes no friction hence velocity stays constant.

Next, we need the ‘state error’, aka P in Kalman articles. I find it usually works fine to start filtering with this as 1. (Perhaps this should be scaled to match your typical values.)

```
Matrix pStateError = {
tl: 1, tr: 1,
bl: 1, br: 1,
}
```

Next, we need our ‘current state’, aka X in Kalman articles. If, like me, you’re faking the velocity, start the filter with this set using the first two measurements:

```
Vector xCurrentState = {
a: data[1],
b: data[1] - data[0], // Faux velocity.
}
```

Phew! Now for the interesting bit. For each new data point/measurement, we need to first predict what it’ll be, then blend that prediction with the measurement to produce an estimate. This estimate is the filter’s output. A ‘Kalman gain’ (known as K in Kalman articles) is calculated then is used to weight the prediction vs measurement when blending them to form the estimate:

```
// Make predictions.
Vector xPredicted = F_STATE_TRANSITION * xCurrentState
Matrix pPredicted = F_STATE_TRANSITION * pStateError * transpose(F_STATE_TRANSITION) + Q_EXTERNAL_NOISE_VARIANCE
// Update it with the measurement.
Vector zMeasurement = Vector {
a: data[current_index], // Position.
b: data[current_index] - data[previous_index] // Faux velocity.
}
Matrix kKalmanGain = pPredicted * invert(pPredicted + R_MEASUREMENT_NOISE_VARIANCE)
Vector xEstimate = xPredicted + kKalmanGain * (zMeasurement - xPredicted)
Matrix pEstimate = pPredicted - kKalmanGain * pPredicted
// Store for the next iteration.
pStateError = pEstimate
xCurrentState = xEstimate // This is the output!
```

Thanks for reading, I hope this helped, God bless, and have a nice week :)
